Himiway Zebra D5| 750W Hub Motor, Long Range Fat Tire E-Bike-ST

$2,299.00 $1,699.00 Save 26%
/
Shipping calculated at checkout.
Color
  • No Tax
  • Free Shipping
  • In stock, ready to ship
  • Backordered, shipping soon

Himiway| Zebra D5-750W Hub Motor, Long Range Fat Tire E-Bike-Step-Thru

Dominate Every Trail with the D5 Electric Fat Tire Mountain Bike

750W Fat ebike Engineered for Mountain Warriors

🏆 "Best Value Mountain ebike 2025" - OutdoorGear Lab

🚚 Free Shipping | 🔧 2-Year Warranty | 🔄 15-Day Returns

Why Mountain Riders Choose D5

⛰️ Conquer Technical Terrain

4.0" Kenda fat tires + 95mm suspension eat rocks for breakfast

🔋 80-Mile Range

48V Samsung battery lasts 3X longer than standard mountain ebikes

Built for Fat ebike Adventures

Winter Warrior Ready

Our 26×4.0" electric fat bike dominates:

  • ❄️ Snow-packed forest trails
  • 🏖️ Deep sand beaches
  • 🌧️ Muddy mountain passes

"D5 handles snow better than my 4X4 truck!" - Mike, Colorado Rider

"Age has been slowing me down but with this HIMI-ebike I'm back in the game" - Over 40 Rider

Mountain ebike Technology

Pro-Grade Components

  • Shimano Altus 7-Speed: Perfect gear range for 15%+ climbs
  • Tektro Hydraulic Brakes: 180mm rotors stop on dime
  • Torque Sensor: Instant 85Nm power when you need it

Your Mountain Awaits

Ready to Ride?

🚴♂️ 10000+ Riders Configured

5'3" to 6'5" Rider Friendly

Specs

Geometry

Recommended Height: 5'3" ~ 6'5"

total length 78.7
handlebar height 47
handlebar length 28
wheelbase 49.2
wheel diameter  28.7
minimum seat height 20.9
maximum seat height 31.4
chain stay length 19
frame stack 24.6
frame reach 17.8
effective top tube length 24.6
head tube length 5.5
head angle 65
standover height ST 22.4/SO 31.1



Frame   6061 Aluminum frame
Headset Neco H156EM 28.6*44-56*30
Fork TRAMA 26""FAT34-26-HLO 95mm travel 9*135mm quick release
Front wheel Rim: MD-147 26*4.0"*36H*12G A/V | Spoke: 12G 255/256L stainless (304M) | Hub: MB015-92 M9*12G*135*145W
Rear wheel Rim: MD-147 26*4.0""*36H*12G A/V Spoke: 12G 214L stainless (304M) Hub: 48v 750w Himiway hub motor
Tires Kenda 26*4.0
Battery Samsung/LG 48V 20Ah
Motor 750W brushless gear motor
Display LCD display with USB charger
Throttle Thumb throttle
Sensors Torque sensor丨speed sensor丨brake sensor
Crankset Crankarm: Prowheel EB-01-242A-S1 170mm | Chain ring: 44T BCD104
Freewheel Shimano MF-TZ500-7 14-28T
Chain KMC Z8.3 EPT 120L
Groupset Shimano altus M310 7 speed
Front brake Tektro HD-E3520 hydraulic brake
Rear brake Tektro HD-E3520 hydraulic brake
Rotors Tektro TR180-52 F:180mm R:180mm

Components

Stem   Zoom TDS-C269-8FOV 31.8*90mm
Handlebar Promax HB-3188 22.2*31.8*700mm
Seatpost
 Himiway Seatpost
Saddle Himiway Saddle
Pedal Aluminum pedal
Lights 48V LED light
Kickstand Heavy-duty aluminum kickstand

Others

Range 60-80 miles
Controller 48V/ 22A
Charger US standard 3.0 A Smart charger
Rider height 5'3" ~ 6'5"
Weight 79 lb. (with battery)
Max. payload capacity 400 lb.

Recommended Height

What is included

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

960Wh Samsung/LG Lithium-ion Battery

It combines the new Samsung/LG battery technology with a 5000mAh single cell capacity in a smaller size but with larger diversity. Compared with 3500mAh cells made of nickel, cobalt, and manganese, this 960Wh battery efficiently improves the range, stability, and safety of Himiway bikes. A single charge can last up to 60 miles on pure electric power and 80+ miles with pedal assist. The battery will maintain 80% capacity after 1000 charges.

400 lb. Payload With 2X Thicker Frame

It boasts an upgraded 6061 Aluminum frame that is 2 times thicker than conventional bike frames, with an integrated battery design. This robust frame can support weights of up to 400lbs, while maintaining the stability of the motor and battery. Riding the D5 feels like being on a tank when going off-road, providing a solid, safe, and reliable riding experience.

Aerospace Grade Aluminum Frame

Hydraulic Brakes

Hydraulic brakes provide superior braking performance and durability. With proper maintenance, there won't be a decline in braking power for 5 years.

48V 500LM Luminosity Spotlight

The Himiway independent R&D luminosity spotlight is 20% brighter than LED light.

Visibility is improved to guarantee your safety while riding at night.

.

Customized Integrated Brake Light

The automatic brake light with Himiway logo will be activated whenever you use the brake, which can prevent rear-end collisions while riding at night.

Thumb Throttle

The thumb throttle are designed for professional cycling enthusiast. Your both hands are more capable of keeping the balance of Himiway Rhino/Rhino pro.

Kenda All-terrain Fat Tire

26"x4" Kenda K-shield fat tires provide strong grip and traction on rugged roads.

Even on the most challenging terrains and weather conditions, these fat tires can guarantee your safety and offer you an easy and smooth riding experience.
