| General | |
|---|---|
| Performance & Power | |
|
Motor
|
Dual 500w hub motor powered by Bafang
|
|
Battery
|
48V 15AH 720 watt hours upgradeable to
20ah internal battery and 14ah dual battery |
|
Range
|
Up to 48 miles on the standard battery, up to
65 miles using the 20AH upgrade, and up to 110 miles using the dual battery technology |
|
Speed
|
Up to 28mph
|
|
Drive Type
|
AWD
|
|
Throttle
|
Thumb Throttle on right side
|
|
Performance
|
1,500w peak rating, 140Nm of torque,
1,000w nominal power |
| Physical Components | |
|
Gear System
|
Single-speed drivetrain with 5 Levels of power assist levels- NO Fuss, NO Hassle, ALL the POWER
|
|
Display
|
Featuring Adjustable Class System (ACS) and waterproof
|
|
Frame
|
Hydroformed aluminum alloy 6061 T6 heat
treated, tig welded to the highest specifications. |
|
Tires
|
All Terrain Capable Kenda 24”x 4” Tire with Anti Puncture Technology
UPGRADE: Tannus Armor—Don’t live in fear of flat tires. Tannus Armous is proven to eliminate 90% of all punctures by providing a layer of protection between the tube and the ground. |
|
Chain
|
KMC Branded Single Speed 1/2" X 1/8"
|
|
Seat
|
UPGRADE: Cloud 9 Airflow Saddle Seat—Ultra wide, thick padding and built for extra-long rides across trails or tough terrain, this seat is the top recommendation from hunters.
UPGRADE: Cloud 9 Sport—Designed with memory foam comfort and to keep you in pursuit of your passion longer than ever before. |
|
Pedals
|
Extra wide Wellgo aluminum alloy
UPGRADE: Extra Wide pedals equipped with gripping traction pins to keep your feet in place as you tackle the toughest terrain. Snow, mud, and rocky ground are no match for these pedals. |
|
Brakes
|
Logan 4 piston 203/180mm
|
| Capacity & Weight | |
|
Load Capacity
|
300 Lbs
|
|
Weight
|
69lbs. with battery removed.
Battery weight 9lbs. |
