| General |
| Performance & Power |
|
Motor
|
Bafang dual 1000w hub motors
|
|
Battery
|
48V 20AH internal battery OR 48V 30AH
|
|
Range
|
Equipped with the 20Ah dual battery system, the Hellcat delivers an impressive range of up to 65–110 miles. Upgrade to the 30Ah option, and you can go even farther—up to 95–140 miles on a single charge
|
|
Speed
|
Up to 32mph.
|
|
Drive Type
|
AWD
|
|
Throttle
|
Adjustable Left or Right Side Thumb Throttle
|
|
Performance
|
2,500w peak rating, 180Nm of torque, 2,000w nominal power
|
| Physical Components |
|
Gear System
|
Shimano Wide Range 8 Speed 11-40T.
|
|
Display
|
Featuring Adjustable Class System (ACS) and waterproof
|
|
Frame
|
Hydroformed aluminum alloy 6061 T6 heat treated, tig welded to the highest specifications.
|
|
Tires
|
Maxxis Minion 26 x 4.0 aggressive tread tires
|
|
Chain
|
KMC Branded Z8. Specially made for high-performance E-Bike power
|
|
Seat
|
UPGRADE: Cloud 9 Airflow Saddle Seat—Ultra wide, thick padding and built for extra-long rides across trails or tough terrain, this seat is the top recommendation from hunters.
UPGRADE: Cloud 9 Sport—Designed with memory foam comfort and to keep you in pursuit of your passion longer than ever before.
|
|
Pedals
|
Extra wide Wellgo aluminum alloy
UPGRADE: Extra Wide pedals equipped with gripping traction pins to keep your feet in place as you tackle the toughest terrain. Snow, mud, and rocky ground are no match for these pedals.
|
|
Brakes
|
Front Brake: 180mm Logan with dual-piston pads and integrated electric safety cutoff Rear Brake: 180mm Logan with dual-piston pads and integrated electric safety cutoff
|
| Capacity & Weight |
|
Load Capacity
|
300 Lbs
|
|
Weight
|
79Lbs with battery removed. Battery weights 11 lbs
|
