Velowave Grace 2.0 Fat Tire Step-Thru Ebike 750W BAFANG 48V 80Mi Class 3
Get ready to conquer any terrain with Velowave’s high-end model—the fat tire off-road E-Bike. With fat tires that offer puncture resistance and stability, this fast off-road E-Bike is built to tackle even the most challenging trails. Experience the ultimate thrill of riding with a powerful 750-watt electric bike, featuring a BAFANG motor and a 48V 20Ah LG high-capacity battery for extended adventures. Whether you’re cruising through the city or exploring rugged trails, the step-through bicycle design ensures easy access and a comfortable riding experience.
Specs & Size
| Frame Size | Standard (mm) |
| Handlebar Height | 1230mm |
| Reach | 420mm |
| Head Tube Length | 175mm |
| Seat Tube Length | 457mm |
| Standover Height | 375mm |
| Wheelbase | 1205mm |
| Total Length | 1940mm |
| Seat Height Min/Max | 880/1060mm |
General
- Classes:Class 3(Ebikes can go up to 28mph with pedal assistance)
- Max Speed:Avg. 80 Miles* on PAS, up to 120 Miles on Level 1, 20 Miles* on Throttle.
- Range:80 Miles Max Range by Pedal; 56 Miles by Throttle(Calculation based on rider's weight of 75kg. Range varies according to road condition, weather, rider's weight etc.)
Frameset
- Frame: 6061 Aluminium, Removable Battery, Internal Routing
- Fork: Hydralic Suspension Fork
Wheels
- Rim Material: Aluminum
- Rim Size: 26 x 3.0
- Front Wheel Spokes: 13K x 243
- Rear Wheel Spokes: 12K x 198
- Tire: CST Fat Tires
- Tire Size: 26" x 4.0"
E-system
- Battery:48V 20Ah, 960Wh, LG 21700 Cells
- Charger: Input 100-240V~, 2.8A(Max.), 50-60Hz. Output 54.6V⎓2.0A, Aviation Connector. UL LISTED
- Motor:BAFANG Geared Hub Motor, Rated 750W, Peak 1000W, Max Torque 80NM
- Controller: 48V 25A Peak
- Display: Multifunctional Color-Screen Display
- Pedal Assist:Torque Sensor
- Throttle: Thumb Throttle
- Front Light: 48V 10W LED Light
Drivetrain
- Shifter: Shimano, 7-Speed
- Rear Derailleur: Shimano, Long Cage
- Crank & Chainring: 52T, 170mm Alloy Crank
- Freewheel: 7-Speed
- Pedal: Alloy Platform Pedals
Components
- Saddle: Comfortable Wide Saddle
- Handlebar:Alloy, 750mm width
- Grips: Nylon Lock-on
- Brake: Front & Rear Hydralic Disc Brakes
- Brake rotor: 180mm, 1.9mm thick
- Kickstand: Side Kickstand
- Seatpost:Forged Alloy, ∅30.4*350mm
- Stem:Bar bore: ∅31.8mm, Clamp I.D.: ∅28.6mm, HEIGHT: 40mm, RISE: 0°
- Handlebar:Aluminum Ø31.8mm, Width 730mm
Weight
- Net Weight:38.5kg
- Gross Weight:50.5kg
- Battery Weight:5.15kg
- Weight limit:150kg(330lb) Payload Capacity
Size
- Product Size:2100x690x1158mm
- Packing Size:1590x330x880mm
What is in the box
Electric Bike x 1
Charger x 1
Battery x 1
Headlight x 1
Spare Spokes x 2
Pedals x 2
Front Reflector x 1
Rear Reflector x 1
Rear Reflector x 1
Three Way Allen Wrench x 1
Allen Wrench x 2
Front Axle Skewer x 1
Spare Screws x 2
Open End Wrench x 2 Screw Driver x 1
Grace 2.0 Step-Thru
Get ready to conquer any terrain with Velowave’s high-end model—the fat tire off-road E-Bike. With fat tires that offer puncture resistance and stability, this fast off-road E-Bike is built to tackle even the most challenging trails. Experience the ultimate thrill of riding with a powerful 750-watt electric bike, featuring a BAFANG motor and a 48V 20Ah LG high-capacity battery for extended adventures. Whether you’re cruising through the city or exploring rugged trails, the step-through bicycle design ensures easy access and a comfortable riding experience
Key Features
Torque Sensor
The torque sensor enhances your pedaling efforts by amplifying your cadence. As you pedal harder, it delivers more output, aligning with your natural rhythm to optimize battery usage and extend your riding range, making it ideal for those seeking a long-range ebike.
750W BAFANG Motor
Featuring a powerful 750-watt electric bike motor for stable and effortless riding, delivering strong electric power and reaching impressive speed peaks with ease.
This motor makes the Grace Step-Thru one of the best fat tire electric bikes for performance and adventure.
48V 20Ah Battery
Equipped with a high-capacity big battery, this 48V/20Ah lithium battery provides a range of up to 120 miles per full charge. The detachable waterproof battery supports fast charging, reaching 80% in 4 hours and a full charge in 8 hours, making it the perfect long-range e-bike for extended rides.
Front Suspension
Ensures a stable and comfortable ride by minimizing vibrations, enhancing control, and increasing safety by preventing hands from leaving the handlebars. Whether riding through rough terrain or city streets, this feature enhances the overall off-road ebike experience.
Fat Tire Design
Fat Tire Design Features Kenda 26" x 4.0" Fat Tires provide superior grip and stability, ensuring a smooth ride on various terrains, including snow and sand. These durable tires make this one of the best fat tire electric bikes for all-season riding.
Shimano Drivetrain
Smooth and efficient Shimano 7-speed drivetrain for easy adjustment of riding speed across different terrains and conditions, ensuring a powerful yet effortless riding experience.
Front Headlight
Smooth-shifting Shimano 7-speed drivetrain for seamless adjustment of riding speed across different terrains and conditions.
Smart Display
Features front and rear hydraulic disc brake system for smooth braking in any condition, along with essential le data including assist level, battery indicator, riding speed, and mileage.
Comfortable Wide Saddle
Designed with a widened and enlarged comfortable seat pad for a more enjoyable riding experience, focusing on every detail for rider comfort. Whether you're commuting or exploring trails, this feature enhances the experience on this step-through bicycle.
